Lambda Fractal

A centered complex logistic map: one parameter both stretches an orbit and turns it back on itself.

Open in Explorer
Black Lambda set against blue-green space, its edge trailing branching threads
The centered complex logistic map’s parameter plane: a disk-like core, attached bulbs, and a threadlike edge.

Overview

On the real line, the logistic map became a small laboratory for chaos. Let its values roam the complex plane and it opens into the Lambda, or λ-, fractal. FractalPark uses a centered form: c scales two complementary factors pulling in opposite directions.

An affine change of coordinates makes this formula conjugate to the standard quadratic map z² + c. It shares the Mandelbrot set’s family traits, but not its outline: here there is a disk where the Mandelbrot set has a cardioid, and the attached bulbs arrange themselves by their own periods.

Here c turns two knobs at once—growth and rotation. Fix it for a Julia view, then nudge it: a nearly round basin can become a boundary of branches and spirals.

The Mathematics

Complex logistic iteration

z(n+1) = c times (z(n) + 1/2) times (1/2 - z(n))

At each step, shift the current value halfway either side of center, multiply (z + ½) by (½ − z), then scale the product with c. The two factors make ¼ − z², so the same step reads z → c(¼ − z²).

Try c = 2 with z₀ = 0. The first step is z₁ = 2 × (½) × (½) = 0.5; the next is z₂ = 2 × 1.0 × 0 = 0. The orbit now shuttles between 0 and 0.5: a stable 2-cycle. Turn c up to 4 and the pull changes: z₁ = 4 × ½ × ½ = 1, then z₂ = 4 × 1.5 × (−0.5) = −3. The orbit diverges, so c = 4 lies outside the bounded set. In Julia mode, hold c still and vary z₀ across the image; the dividing line between trapped and escaping appears.

History

The map z → λz(1 − z) began as the complex extension of the real logistic map, studied extensively in the 1970s as a simple model of population dynamics and chaotic behavior. In 1980, Benoit B. Mandelbrot took the iteration to unrestricted complex λ and z. His paper, "Fractal Aspects of the Iteration of z → λz(1−z) for Complex λ and z," introduced the λ-plane parameter set—now the Lambda fractal—and placed it in the broader theory of iterated rational maps.

The groundwork was already there. Around 1917–1918, Pierre Fatou and Gaston Julia developed the general theory of iterated rational functions that later made families such as the logistic map available to explore. In 1986, Heinz-Otto Peitgen and Peter H. Richter brought the Lambda fractal to a wider audience in "The Beauty of Fractals," with some of the first widely seen computer-generated images of the set.

Visual Characteristics

At full scale, the Lambda set begins with an almost circular body—the countershape to the Mandelbrot set’s heart-like cardioid. Smaller bulbs cling to the disk; each marks a stable periodic cycle, and the largest marks a period-2 cycle. Beyond them lie branching channels, tiny disk islands, and spirals.

The islands give away the difference: they are round here, not cardioid-shaped, because the algebra has changed. In Julia mode, c can select a filled disk or a many-armed vortex.

Remix and Examples

Start from the canonical Document

Open the same approved formula state used by this guide, then change the view, coloring, transforms, or animation in the interactive Explorer.

Remix in ExplorerOpen Formula Editor

Frequently Asked Questions

What does lambda control?

The complex parameter c—often written λ in the literature—sets both the orbit’s growth rate and its rotation. Its magnitude controls the strength of expansion or contraction; its argument supplies the turn at each step.

Why does Julia mode look especially varied?

Fix c and the question shifts to the starting point: does it stay bounded or escape? With linear and quadratic terms in the same formula, the border may be a smooth closed curve or a heavily branched connected set. The chosen c decides what the renderer reveals.
